04 · System
LC180-A30 — 1.5kW System
Universal-input turnkey system for 24V/36V/48V platforms
ULCSAFCCCERoHSREACHcertified
A plug-and-play 1.5kW wireless charging system with a wide output range, compatible with 24V, 36V and 48V battery systems. Universal AC input makes deployment simple anywhere in the world.
Typical applications
AGVs & AMRsWarehouse robotsService robotsIndustrial automation equipment
Specifications
↓ Download datasheet (PDF)| Continuous charging power | 1500W Max |
| AC input | 100–240V AC, 47–63Hz |
| Charging voltage | 18–60V (24V / 36V / 48V platforms) |
| Charging current | 30A Max |
| Transfer efficiency | >80% |
| Operating frequency | 140kHz |
| Charging distance | 10–30mm (optimal 20mm) |
| Position tolerance | ±20mm (X/Y) |
| Coil variants | A: bottom mount / B: side mount |
| Suitable batteries | Li-ion, LiFePO4, lead-acid, LTO, NiCd |
| Protection class | Coils IP65; RX controller IP54; TX controller IP20 |
| Protection features | OVP, OCP, OTP, short-circuit, overload |
| Communication interface | CAN / RS485 |
| Certifications | UL 1564, CSA C22.2, FCC Part 15, CE (EMC), RoHS, REACH |
Engineering resources
CAD files, 3D models and protocol documentation are available on request — tell us about your application.
Key features
- Wide output range covers most AGV/AMR battery platforms
- Universal AC input for global deployment
- Automatic charge start/stop — zero worker intervention
- IP65/IP54 sealed pads for demanding environments
Need a different spec?
Output voltage and current can be configured within range to match your battery. Hardware changes are possible as a development project — talk to us first.
