LS300-A60 — 3kW System
Heavy-duty contactless charging for AGVs and forklifts
ULCSAFCCCEREACHcertified
A complete AC-input wireless charging system for heavy industrial vehicles. Mount the transmitter pad, connect to mains power, and your fleet charges automatically at every stop — no plugs, no contacts, no wear.
Typical applications
AGVs & AMRsUnmanned forkliftsMobile robotsAutomated warehouse vehicles
Specifications
↓ Download datasheet (PDF)| Continuous charging power | 3000W Max |
| AC input | 1-phase 200–240V AC, 50/60Hz, 16A Max |
| Charging voltage | 58V rated (42–58V range) |
| Charging current | 60A Max |
| Transfer efficiency | 90% Max (at optimal distance) |
| Operating frequency | 85kHz |
| Charging distance | 20–45mm (optimal 40mm) |
| Position tolerance | ±40mm single axis (X or Y); ±25mm both axes |
| Suitable batteries | Lithium, LiFePO4 |
| Protection class | Coils IP65; RX controller IP54; TX controller IP20 |
| Protection features | OVP, OCP, OTP, short-circuit, overload |
| Communication interface | CAN / RS485 |
| Certifications | UL 1564, CSA C22.2, FCC Part 15/18, CE (EMC), REACH |
Engineering resources
CAD files, 3D models and protocol documentation are available on request — tell us about your application.
Key features
- Opportunity charging — top up at every stop to extend fleet uptime
- Sealed, contactless design: no corrosion, no connector wear
- Designed for 58V-class lithium battery systems (42–58V)
- CAN / RS485 communication for fleet and BMS integration
Need a different spec?
Output voltage and current can be configured within range to match your battery. Hardware changes are possible as a development project — talk to us first.
